ASUS ROG Rapture GT6

Name: ASUS ROG Rapture GT6
Brand: ASUS
SKU: ROG Rapture GT6

Released Aug 2022

The ROG Rapture GT6 is a high-performance tri-band Wi-Fi 6 mesh system (AX10000) designed for gamers. It features a 1.7 GHz tri-core processor, a 2.5 Gbps WAN port, and nine internal antennas, including a smart antenna designed to optimize backhaul connections. It supports triple-level game acceleration, AiProtection Pro, and the expanded 5.9 GHz (UNII-4) band for enhanced bandwidth.

Wi-Fi

WiFi 6 (802.11ax)

RAM

512 MB

CPU Cores

LAN Ports

At a glance

Highlights

Wi-Fi WiFi 6 (802.11ax)

Supports IPv4, IPv6, WiFi (802.11a), WiFi (802.11b), WiFi (802.11g), WiFi 4 (802.11n), WiFi 5 (802.11ac), WiFi 6 (802.11ax)

Dual-band

2.4 GHz · 5 GHz

3 × Gigabit LAN

1 Gigabit WAN port

Mesh: Yes, Primary and Node

Compatible with mesh networking

Built-in VPN

Client: L2TP, OpenVPN, PPTP, WireGuard · Server: IPSec, OpenVPN, PPTP, WireGuard

Gaming Acceleration

Prioritized routing for gaming traffic

Every detail

Full Specifications

General

9 specs

Manufacturer

ASUS

Model

ROG Rapture GT6

Full Name

ASUS ROG Rapture GT6

Homepage

Open website

Release Date

2022-08-23

Currently Sold

Yes

Manufacturer Support

Yes

Operating System

ASUS WRT

Mesh Integration

Yes, Primary and Node

Hardware

5 specs

Processor Speed (MHz)

1700

CPU Cores

RAM (MB)

512

Flash (MB)

256

Internal Antennas

Connectivity

13 specs

Network Standards

IPv4 IPv6 WiFi (802.11a) WiFi (802.11b) WiFi (802.11g) WiFi 4 (802.11n) WiFi 5 (802.11ac) WiFi 6 (802.11ax)

Operating Modes

Accesspoint AiMesh Node Router

2.4 GHz Support

Yes

5 GHz Support

Yes

6 GHz Support

Gigabit WAN Ports

Gigabit LAN Ports

LAN Aggregation

Yes

WAN Aggregation

Yes

USB Ports

USB-A (3.2) (1)

WAN Connection Types

Automatic IP L2TP PPPOE PPTP Static IP

Cable Modem

Fibre Modem

Core Features

8 specs

VPN Clients

L2TP OpenVPN PPTP WireGuard

VPN Servers

IPSec OpenVPN PPTP WireGuard

Smart Home Integrations

Alexa IFTTT

Mobile App

ASUS Router App

WPS Button

Yes

Reset Button

Yes

Power Switch

Yes

LED Switch

Physical

11 specs

Weight (g)

880.00

Length (mm)

172.30

Width (mm)

78.10

Height (mm)

176.75

110V Power Supply

Yes

220V Power Supply

Yes

Horizontal Positioning

Yes

Vertical Positioning

Wall Mountable

Package Content

ROG Rapture GT6, RJ-45 Cable, Power Adapter, Quick Start Guide, Warranty Card

Warranty (Years)

Features Matrix

all software features at a glance

Wi-Fi

IPv6 MU-MIMO Encryption UTF-8 SSID Guest Network WPS MAC Filter Scheduler Airtime Fairness RADIUS Server Universal Beamforming Explicit Beamforming IGMP Snooping

QoS & Traffic

Parental Control Adaptive QoS Traditional QoS Bandwidth Monitor Bandwidth Limiter Traffic Monitor Traffic Analyzer Website History Gaming Acceleration

WAN & LAN

Dual WAN 3G/4G Dongle Android Tethering Port Forwarding DDNS DMZ NAT Passthrough Port Triggering DHCP Server IPTV LAN Link Aggregation

USB & Storage

File System HDD Hibernation Safely Remove Download Master Media Server Time Machine Samba FTP Shared Folder Cloud Access

Admin & Security

Firewall Wake on LAN SSH Access Config Backup/Restore Diagnosis Tools Feedback System System Log Antivirus Site Blocking Auto Firmware Update

About these specifications

Specifications are compiled from ASUS's official product documentation and publicly available technical datasheets. All trademarks, product names, and imagery are the property of their respective owners; RouterArena is not affiliated with or endorsed by the manufacturer.

Spotted an inaccuracy? Let us know — we update pages as new information becomes available.
